Rubberized bitumen membrane 1m x 10m welded KMS 17

Product code 713850
Package size 24 rl
rl

Product details

Rubber-bitumen membrane for new construction and renovation for waterproofing and moisture protection of foundation walls.

Kerabit 4000 BASE KMS 170/4000 is a weldable SBS elastomer and bitumen-based, polyester-reinforced underlay and intermediate membrane with high elongation and elasticity, suitable for two- or multi-layer waterproofing. It meets the roofing association’s product class TL 2, the RIL 107-2012 guideline, as well as the EN 13707 and EN 13969 standards. The membrane is intended for use as an underlay and intermediate layer on roofs with slopes ≥ 1:80 in both new construction and renovation projects. It is also commonly used for water and moisture protection.

Waterproofing with bitumen membranes is performed using a bonding primer and welding the KMS 170/4000 across the entire surface. For water pressure insulation, 2-4 layers of KMS 170/4000 membrane are used, depending on the water pressure.

Sales unit rl
Size 1 x 10m
Material bitumen
Colour black
Usage unit m
Conversion factor 10
Length of the sales unit (mm) 1000
Width of the sales unit (mm) 220
Height of the sales unit (mm) 220
Weight of the sales unit (kg) 40
Package type pallet
Brochures
Certificates
  • 713850_SFK_Kumibitumikermi 1m x 10m hitsattava KMS 170-4000.pdf (207 kt) Open Download
Declaration of performance
  • 713850_STI_Kumibitumikermi 1m x 10m hitsattava KMS 170-4000.pdf (102 kt) Open Download
Product specifications
  • 713850_TS_Kumibitumikermi 1m x 10m hitsattava KMS 160-4000.pdf (98 kt) Open Download
Safety data sheets
  • 713850_KTT_Kumibitumikermi 1m x 10m hitsattava KMS 170-4000.pdf (154 kt) Open Download
Technical specifications
  • 713850_TE_Kumibitumikermi 1m x 10m hitsattava KMS 160-4000.pdf (164 kt) Open Download
